1767070

Phoenix Contact COMBICON GMSTB 系列 7.62mm 节距 9 路 母 绿色 插头 1767070, 螺钉端接

Conn Terminal Block F 9 POS 7.62mm Screw RA Cable Mount 12A

欧时:
Phoenix Contact 1767070 COMBICON GMSTB 系列 7.62mm 节距 9 路 母 插头, 螺钉端接 绿色

得捷:
TERM BLOCK PLUG 9POS STR 7.62MM

立创商城:
插头 7.62mm 排数:1 每排P数:9

艾睿:
Phoenix Contact&s;s 1767070 PCB terminal block will ensure strong connections between circuits. This F connector has 9 contacts that are plated with tin. It has a maximum voltage rating of 630 V. This is a 1-row connector. Its pitch is 7.62 mm. It has a female type gender. It has a right angle body orientation. 1767070 is housed in polyamide. This device has a maximum current rating of 12 A. Its wire is 12-24 AWG. This product is 66.58 mm long, 15 mm tall and 18.2 mm deep. It uses the screw termination method.

MASTER:
Conn Terminal Block F 9 POS 7.62mm Screw RA Cable Mount 12A

Online Components:
Conn Terminal Block F 9 POS 7.62mm Screw RA Cable Mount 12A

Electro Sonic:
PCB connector - nominal current: 12 A - rated voltage III/2: 630 V - nominal cross section: 2.5 mm² - ...
