ERJ3EKF9101V

PANASONIC ELECTRONIC COMPONENTS  ERJ3EKF9101V  片式电阻器, 表面贴装, 厚膜, AEC-Q200 ERJ系列, 9.1 kohm, 75 V, 0603 [1608公制], 100 mW, ± 1%

0603 格式器，ERJ3EK 系列 - 1% 5.1Ω-34.8Ω

ERJ 3E 精密厚膜片式电阻器是紧凑、轻型解决方案。 这些片式电阻器由三层电极、金属釉厚膜电阻元件构成，非常可靠。 ERJ 3E 系列具有 ±1% 的低电阻容差，与自动贴片机兼容。 这些精密电阻器具有 AEC-Q200 资格，特别适用于汽车应用。

### 认可

IEC 60115-8，JIS C 5201-8，EIAJ RC-2134B

立创商城:
9.1kΩ ±1% 100mW

欧时:
Panasonic ERJ 系列 0.1W 9.1kΩ 精密厚膜SMD 电阻器 ERJ3EKF9101V, ±1%, ±100ppm/°C, 0603 封装

e络盟:
SMD片式电阻, 0603 [1608公制], 9.1 kohm, ERJ3EK Series, 75 V, 厚膜, 100 mW

艾睿:
Use this ERJ-3EKF9101V fixed single surface-mount resistor from Panasonic to obtain a visually clean layout. This durable part has a power rating of 0.1 1/10 W. This product has a resistance value of 9.1K Ohm. Its temperature coefficient is ±100 ppm/°C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It has a tolerance of 1%. This part has an operating temperature of -55 to 155 °C. This product is 1.6 mm long, 0.45 mm tall and 0.8 mm deep. This device is made with thick film technology.

安富利:
Res Thick Film 0603 9.1K Ohm 1% 1/10W ±100ppm/°C Molded SMD SMD Punched Carrier T/R
