ERA6AEB6810V

PANASONIC ELECTRONIC COMPONENTS  ERA6AEB6810V  片式电阻器, 表面贴装, 薄膜, AEC-Q200 ERA系列, 681 ohm, 100 V, 0805 [2012公制], 125 mW, ± 0.1%

0.125W ERA 系列 0.1% 25ppm - 满卷 47Ω → 976Ω

金属膜片式器是高可靠型且在高温和高湿条件下性能稳定。 Panasonic 金属膜片式电阻器还具有高精确度，带低电阻容差和电阻温度系数，同时具有高执行力，低电流噪声和优异的非线性性能。

### 标准

IEC 60115-8，JIS C 5201-8，EIAJ RC-2133A

欧时:
Panasonic ERA 系列 0.125W 681Ω 金属膜 薄膜SMD 电阻器 ERA6AEB6810V, ±0.1%, ±25ppm/°C, 0805 封装

e络盟:
PANASONIC ELECTRONIC COMPONENTS  ERA6AEB6810V  片式电阻器, 表面贴装, 薄膜, AEC-Q200 ERA系列, 681 ohm, 100 V, 0805 [2012公制], 125 mW, ± 0.1%

艾睿:
Use this ERA-6AEB6810V fixed single surface-mount resistor from Panasonic to obtain a visually clean layout. This product has a resistance value of 681 Ohm. This part has a power rating of 0.125 1/8 W. Its temperature coefficient is ±25 ppm/°C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This product is 2 mm long, 0.5 mm tall and 1.25 mm deep. This part has an operating temperature of -55 to 155 °C. This device is made with thin film technology.

安富利:
Res Thin Film 0805 681 Ohm 0.1% 1/8W ±25ppm/°C Molded SMD SMD Punched Carrier T/R

Chip1Stop:
Res Thin Film 2.0 x 1.2 mm 681 Ohm 0.1% 0.125W1/8W 25ppm/ C Molded SMD Punched Carrier T/R

Verical:
Res Thin Film 0805 681 Ohm 0.1% 0.125W1/8W ±25ppm/C Pad SMD Automotive T/R
