FTSH-108-04-L-DV

SAMTEC FTSH-108-04-L-DV Board-To-Board Connector, 1.27mm, 16Contacts, Header, FTSH Series, Solder, 2Rows

针座 表面贴装型 16 位置 0.050"（1.27mm）

得捷:
CONN HEADER SMD 16POS 1.27MM

艾睿:
Use this unshrouded FTSH-108-04-L-DV header connector from Samtec where IDC ribbon cables are used. This HDR connector&s;s 16 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. This is a 2-row connector. It has a header type gender. Its pitch is 1.27 mm. This device has a maximum current rating of 3.3 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 10.16 mm long, 6.73 mm tall and 5.84 mm deep. It uses the solder termination method. FTSH-108-04-L-DV is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 16 POS 1.27mm Solder ST SMD Tube

Newark:
# SAMTEC  FTSH-108-04-L-DV  Board-To-Board Connector, 1.27 mm, 16 Contacts, Header, FTSH Series, Solder, 2 Rows
