JN5168-001-M06Z

MCU 32Bit JN516x RISC 256KB Flash 3.3V 27Pin SMD

The is an ultra low power, high performance surface mount module targeted at IEEE 802.15.4, JenNet-IP, ZigBee Light Link, ZigBee Smart Energy and RF4CE networking applications. The module uses "s JN5168 wireless microcontroller to provide a comprehensive solution with large memory, high CPU and radio performance and all RF components included. All that is required to develop and manufacture wireless control or sensing products is to connect a power supply and peripherals such as switches, actuators and sensors, considerably simplifying product development.

.

up to 6 km range Ext 2 dBi Antenna

.

22 dBm TX Power

.

No RF test required for systems

.

32-bit RISC CPU, up to 32 MIPs with low power

.

256 kB embedded flash memory, 32 kB RAM

.

4 kB data EEPROM with guaranteed 100k write operations

.

RF4CE, JenNet-IP, ZigBee Smart Energy and ZigBee Light Link stacks

.

4-input 10-bit ADC, 1 comparator

.

5 x PWM 4 x timer, 1 x timer / counter

.

2 UARTs

.

SPI Master & Slave port with 3 selects
