LP2985A-50DBVT

TEXAS INSTRUMENTS  LP2985A-50DBVT  固定电压稳压器, LDO, 2.2V至16V, 280mV压差, 5V输出, 150mA输出, SOT-23-5

LDO（低压降）线性稳压器，150mA，4.0V 至 12V，Texas Instruments

立创商城:
LP2985A-50DBVT

德州仪器TI:
150-mA, 16-V, low-dropout voltage regulator with high-accuracy

得捷:
IC REG LINEAR 5V 150MA SOT23-5

欧时:
### LDO（低压降）线性稳压器，150mA，4.0V 至 12V，Texas Instruments### LDO（低压降）线性稳压器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

贸泽:
LDO Voltage Regulators Sgl Output 150mA Fixed5.0V Lo Quies

e络盟:
固定电压稳压器, LDO, 2.2V至16V, 280mV压差, 5V输出, 150mA输出, SOT-23-5

艾睿:
Stable voltages are always needed for sensitive systems implement this LDO LP2985A-50DBVT linear regulator from Texas Instruments. It has an overall accuracy of ±1 %. Its typical dropout voltage at current is 0.001@0A|0.007@1mA|0.04@10mA|0.12@50mA|0.28@150mA V. This voltage regulation device&s;s single output can produce a current up to 0.15 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.2 V and no higher than 16 V. With a fixed output that has a voltage of 5 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a line regulation of 0.014%/V. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive. The maximum dropout voltage is 0.003@0A|0.01@1mA|0.06@10mA|0.15@50mA|0.35@150mA V.

安富利:
LDO Regulator Pos 5V 0.15A 5-Pin SOT-23 T/R

Chip1Stop:
Single Channel LDO Single Output LDO, 150mA, Fixed5.0V, 1.0% Tolerance, Low Quiescent Current, Low Noise LDO Regulator Pos 5V 0.15A 5-Pin SOT-23 T/R

TME:
Voltage regulator; LDO, fixed; 5V; 0.15A; SOT23-5; SMD; Channels:1

Verical:
LDO Regulator Pos 5V 0.15A 5-Pin SOT-23 T/R

Newark:
# TEXAS INSTRUMENTS  LP2985A-50DBVT  Fixed LDO Voltage Regulator, 2.2V to 16V, 280mV Dropout, 5Vout, 150mAout, SOT-23-5

力源芯城:
具有关断状态的150mA,5V固定的LDO稳压器

DeviceMart:
IC REG LDO 5V .15A SOT23-5

Win Source:
IC REG LDO 5V 0.15A SOT23-5
