TEXAS INSTRUMENTS LMR14206XMK/NOPB 直流-直流开关降压逐步递减稳压器, 可调, 4.5V-42V输入, 765mV-34V输出, 600mA输出, SOT-23-6
降压 开关稳压器 IC 正 可调式 0.765V 1 输出 600mA SOT-23-6 细型,TSOT-23-6
立创商城:
降压型 Vin=4.5V~42V Vout=765mV~34V 600mA
得捷:
IC REG BUCK ADJ 600MA TSOT23-6
德州仪器TI:
4.5V to 42V, 0.6A Step-Down DC/DC Switching Regulator in SOT-23 Package
e络盟:
直流-直流开关降压逐步递减稳压器, 可调, 4.5V-42V输入, 765mV-34V输出, 600mA输出, SOT-23-6
艾睿:
Adjust the voltage level of your devices with this step down LMR14206XMK/NOPB DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 0.6 A. With a small input voltage of 4.5 V and a max of 42 V, this will supply sufficient power to your circuit. With an adjustable output that has a voltage of 0.765 to 34 V, this is power management at its best. This part offers a switching frequency of 1250Typ kHz in order to work properly. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This converter has a minimum operating temperature of -40 °C and a maximum of 125 °C.
安富利:
Conv DC-DC Single Step Down 4.5V to 42V 6-Pin TSOT T/R
TME:
PMIC; DC/DC converter; Uin:4.5÷42V; Uout:0.765÷34V; SOT6; buck
Verical:
Conv DC-DC 4.5V to 42V Step Down Single-Out 0.765V to 34V 0.6A 6-Pin TSOT-23 T/R
Newark:
# TEXAS INSTRUMENTS LMR14206XMK/NOPB DC-DC Switching Buck Step Down Regulator, Adjustable, 4.5V-42Vin, 765mV-34Vout, 600mAout, SOT-23-6
DeviceMart:
IC REG BUCK ADJ 0.6A 6TSOT
输出接口数 1
输出电压 0.765V ~ 34V
输出电流 600 mA
针脚数 6
静态电流 1.30 mA
调节输出数 1
开关频率 1.5 MHz
拓扑结构 Buck
输入电压Max 42 V
输入电压Min 4.5 V
输出电压Max 34 V
输出电压Min 765 mV
输出电流Max 0.6 A
工作温度Max 125 ℃
工作温度Min -40 ℃
输入电压 42 V
安装方式 Surface Mount
引脚数 6
封装 TSOT-23-6
封装 TSOT-23-6
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 工业, 便携式器材, 计量, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LMR14206XMK/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LMR14206XMKE/NOPB 德州仪器 | 类似代替 | LMR14206XMK/NOPB和LMR14206XMKE/NOPB的区别 |
LMR14206XMKX/NOPB 德州仪器 | 类似代替 | LMR14206XMK/NOPB和LMR14206XMKX/NOPB的区别 |
