LB26RKW01

NKK SWITCHES  LB26RKW01  按钮开关, 非发光, DPDT, 3A, 250V

Rectangular 16.2 x 22.4 mm panel mounted pushbutton switch bodies offer versatile solutions to panel switch design. Caps and bright LED lamps, both sold separately, are available in red, amber and green.

立创商城:
LB26RKW01

贸泽:
Pushbutton Switches DPDT On-On RECTANG

e络盟:
按钮开关, 非发光, DPDT, 3A, 250V

艾睿:
Manually control your circuit components with this LB26RKW01 push button switch from NKK Switches. This device has a maximum current rating of 3 A @ 250VAC 30VDC. It has a DPDT configuration. This push switch has an operating temperature range of -25 °C to 70 °C. The LB26RKW01 push switch has a quick connect/solder lug termination style. The maximum AC voltage rating is 250 VAC and the maximum DC voltage rating is 30 VDC. This product is 34 mm tall.

Allied Electronics:
Switch part; pushbtn body; DPDT; Cap/LED sold separate; 16.2x22.4mm pnl mnt

Chip1Stop:
Switch Push Button ON ON DPDT Rectangular Button 3A 250VAC 30VDC Alternate Contact Quick Connect/Solder Lug Panel Mount

Verical:
Switch Push Button ON ON DPDT Rectangular Button 3A 250VAC 30VDC Alternate Contact Quick Connect/Solder Lug Panel Mount

Newark:
# NKK SWITCHES  LB26RKW01  Illuminated Pushbutton Switch, DPDT, On-On, 3 A, 250 V

Powell:
STD SIZE PUSHBUTTON/ILLUMINATED/SNAP-IN
