LM2931ADT-5.0G

LDO（低压降）线性电压调节器，ON Semiconductor低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

低压降 LDO 线性电压调节器，高达 120mA，

得捷:
IC REG LINEAR 5V 100MA DPAK

立创商城:
LM2931ADT-5.0G

欧时:
### LDO（低压降）线性稳压器，ON Semiconductor，最高可达 120mA### LDO（低压降）线性稳压器，ON Semiconductor低压降或 LDO 为线性稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

e络盟:
稳压器, 固定LDO, 40V输入, 160mV压差, 5V/100mA输出, TO-252-3

艾睿:
This LDO LM2931ADT-5.0G linear regulator from ON Semiconductor is used to manipulate the voltage level of your circuit. Its typical dropout voltage at current is 0.015@10mA|0.16@100mA V. It has an overall accuracy of ±3.8 %. This voltage regulation device&s;s single output can produce a current up to 0.1Typ A. The best way to provide power to your application is by using this, which needs a voltage lower than 40 V. With a fixed output that has a voltage of 5 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 50mV and line regulation of 30mV. This product comes in rail packaging to keep individual parts separated and protected. The maximum dropout voltage is 0.2@10mA|0.6@100mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.

Allied Electronics:
LM2931ADT-5.0G, LDO VoltageRegulator, 100mA, 5V +/-3.8%, Max. of 40 Vin, 3-Pin DPAK

TME:
Voltage regulator; LDO, linear, fixed; 5V; 0.1A; DPAK; SMD; ±3.8%

Verical:
LDO Regulator Pos 5V 0.1A 3-Pin2+Tab DPAK Rail

Newark:
# ON SEMICONDUCTOR  LM2931ADT-5.0G  LDO, FIXED, 5V, 0.1A, TO-252-3

DeviceMart:
IC REG LDO 5V .1A DPAK
