LM317D2TG

ON SEMICONDUCTOR  LM317D2TG  芯片, 稳压器 可调 +1.2/37V

LM317 线性稳压器，

**ON Semiconductor LM317** 系列是可调线性稳压器。 3 端子正电压稳压器可提供 1.5A 及更高的输出电流，输出电压介于 1.2 至 37V 之间。 易于使用的 LM317 可调稳压器可用于各种应用，如卡式调节，并可用作可编程输出稳压器；通过在调整和输出之间连接一个固定电阻器，它可用作精密电流稳压器。

输出电压范围：1.25 V 至 37 V

输出电流：1.5 A

短路电流限制、热保护和安全区域补偿

浮动操作，用于高电压应用

### 线性稳压器，On Semiconductor

立创商城:
LM317D2TG

得捷:
IC REG LIN POS ADJ 1.5A D2PAK-3

欧时:
ON Semiconductor LM317 系列 LM317D2TG 线性稳压器, 最大为 40 V输入, 1.2 → 37 V输出 可调

e络盟:
线性稳压器, 可调, 1.2V 至 37V 输入, 1.5A /1输出, TO-263-3

艾睿:
Standard Regulator Pos 1.2V to 37V 1.5A 3-Pin2+Tab D2PAK Rail

Allied Electronics:
LM317D2TG, Single Linear Voltage Regulator, 1.5A Adjustable 1.2 to 37V, 3-Pin D2PAK

Jameco:
Voltage Regulator 1.2V 1.5A

安富利:
The LM317 device is an adjustable three-terminal positive-voltage regulator capable of supplying more than 1.5 A over an output-voltage range of 1.25 V to 37 V. It requires only two external resistors to set the output voltage. The device features a typical line regulation of 0.01% and typical load regulation of 0.1%. It includes current limiting, thermal overload protection, and safe operating area protection Overload protection remains functional even if the ADJUST terminal is disconnected.

Chip1Stop:
Standard Regulator Pos 1.2V to 37V 1.5A 3-Pin2+Tab D2PAK Tube

TME:
Voltage regulator; linear, adjustable; 1.2÷37V; 1.5A; D2PAK; SMD

Verical:
Standard Regulator Pos 1.2V to 37V 1.5A 3-Pin2+Tab D2PAK Rail

Newark:
ADJUSTABLE LDO VOLTAGE REGULATOR, 1.2V TO 37V 1.5A D2-PAK-3

力源芯城:
可调整的3端正电压稳压器

DeviceMart:
IC REG LDO ADJ .5A D2PAK
