LM78L05ACZ/LFT3

LM78LXX系列三端稳压器正 LM78LXX Series 3-Terminal Positive Regulators

PMIC - 稳压器 - 线性 输出 100mA TO-92-3

得捷:
LM78L 100-MA FIXED OUTPUT LINEAR

立创商城:
LM78L05ACZ/LFT3

德州仪器TI:
100-mA, 30-V, linear voltage regulator

贸泽:
线性稳压器 DISC-RESTRICTED-PART

艾睿:
Never worry about components seeing unstable voltages again by implementing this standard LM78L05ACZ/LFT3 linear regulator manufactured by Texas Instruments. It has an overall accuracy of ±5 %. This device has a maximum power dissipation of 750 mW. This voltage regulation device&s;s single output can produce a current up to 0.1 A. Using the part will provide the power your application needs by requiring a voltage only of 6.7 V and not exceeding a voltage of 35 V. With a fixed output that has a voltage of 5 V, this is power management at its best. To produce a constant current at your output, supply your circuit with a load regulation of 60mV and line regulation of 75mV. Its maximum power dissipation is 750 mW. This voltage regulation device has an operating temperature range of 0 °C to 125 °C. Its polarity is positive.
