LDO(低压降)线性电压稳压器,STMicroelectronics,高达 100mA### LDO(低压降)线性电压调节器,STMicroelectronics低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
LDO(低压降)线性电压稳压器,STMicroelectronics,高达 100mA
欧时:
### LDO(低压降)线性电压稳压器,STMicroelectronics,高达 100mA### LDO(低压降)线性电压调节器,STMicroelectronics低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
得捷:
IC REG LINEAR 5V 100MA SOT89-3
立创商城:
正 Vin=16V Vout=5V 100mA 63dB@1kHz
贸泽:
LDO Voltage Regulators 5.0V 100mA Positive
e络盟:
固定电压稳压器, LDO, 2.5V至16V, 180mV压差, 5V输出, 100mA输出, SOT-89-3
艾睿:
This LDO LD2981ABU50TR linear regulator developed by STMicroelectronics keeps the power stable! It has an overall accuracy of ±0.75 %. Its typical dropout voltage at current is 0.001@0A|0.007@1mA|0.07@25mA|0.18@100mA V. This voltage regulation device&s;s single output can produce a current up to 0.1 A. This will operate at a minimum voltage of 2.5 V and a maximum voltage of 16 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 5 V, this is power management at its best. Maintain a constant voltage level with a line regulation of 0.014%/V. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. The maximum dropout voltage is 0.003@0A|0.01@1mA|0.1@25mA|0.25@100mA V. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.
安富利:
LDO Regulator Pos 5V 0.1A 4-Pin3+Tab SOT-89 T/R
Chip1Stop:
LDO Regulator Pos 5V 0.1A 4-Pin 3+Tab SOT-89 T/R
Verical:
LDO Regulator Pos 5V 0.1A 4-Pin3+Tab SOT-89 T/R
儒卓力:
**LDO VREG 5V 0.1A SOT89 **
力源芯城:
100mA,5V固定输出,LDO稳压器
DeviceMart:
IC REG LDO 5V .1A SOT-89
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 5V 100mA SOT-89-3
输出接口数 1
输入电压DC 16.0V max
输出电压 5 V
输出电流 100 mA
供电电流 150µA ~ 2.6mA
针脚数 3
静态电流 0.08 mA
跌落电压 180 mV
输入电压Max 16 V
输入电压Min 2.5 V
输出电压Min 5 V
输出电流Max 100 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±0.75 %
输入电压 16 V
安装方式 Surface Mount
引脚数 3
封装 SOT-89-3
长度 4.6 mm
宽度 2.6 mm
高度 1.6 mm
封装 SOT-89-3
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Power Management, 音频, 便携式器材, Imaging, Video & Vision, 视频和目视, 成像, Consumer Electronics, Audio, Portable Devices, 计算机和计算机周边, Computers & Computer Peripherals, 电源管理, 消费电子产品
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LD2981ABU50TR ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
LD2981CU50TR 意法半导体 | 类似代替 | LD2981ABU50TR和LD2981CU50TR的区别 |
LD2980CU50TR 意法半导体 | 类似代替 | LD2981ABU50TR和LD2980CU50TR的区别 |
LD2980ABU50TR 意法半导体 | 类似代替 | LD2981ABU50TR和LD2980ABU50TR的区别 |
