2A 至 3A,ON Semiconductor### 标准Products with NSV- or SUR-prefixed Manufacturer Part Nos are AEC-Q101 automotive qualified.### 二极管和整流器,ON Semiconductor
整流器,2A 至 3A,
### 标准
带 NSV- 或 SUR- 前缀的制造商部件号符合 AEC-Q101 汽车等级。
立创商城:
功率整流器,超快速恢复,2 A,200 V
得捷:
DIODE GEN PURP 200V 2A SMB
欧时:
### 整流器二极管,2A 至 3A,ON Semiconductor### 标准带 NSV- 或 SUR- 前缀的制造商部件号符合 AEC-Q101 汽车等级。### 二极管和整流器,ON Semiconductor
贸泽:
Rectifiers 200V 2A Ultrafast
e络盟:
快速/超快二极管, 200 V, 2 A, 单, 950 mV, 25 ns, 40 A
艾睿:
Converting from AC to DC is simple when using a switching diode MURS220T3G rectifier from ON Semiconductor. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This rectifier has a minimum operating temperature of -65 °C and a maximum of 175 °C. It is made in a single configuration. Its peak non-repetitive surge current is 40 A, while its maximum continuous forward current is 2 A.
安富利:
Diode Switching 200V 2A 2-Pin SMB T/R
Chip1Stop:
Diode Switching 200V 2A Automotive 2-Pin SMB T/R
Verical:
Rectifier Diode Switching 200V 2A 35ns 2-Pin SMB T/R
Newark:
# ON SEMICONDUCTOR MURS220T3G Fast / Ultrafast Diode, 200 V, 2 A, Single, 950 mV, 25 ns, 40 A
Win Source:
DIODE GEN PURP 200V 2A SMB
额定电压DC 200 V
额定电流 2.00 A
无卤素状态 Halogen Free
输出电流 ≤2.00 A
正向电压 950 mV
极性 Standard
热阻 13 ℃/W
反向恢复时间 35 ns
最大反向击穿电压 200 V
正向电流 2 A
最大正向浪涌电流(Ifsm) 40 A
正向电压Max 950 mV
正向电流Max 2 A
工作温度Max 175 ℃
工作温度Min -65 ℃
工作结温Max 175 ℃
安装方式 Surface Mount
引脚数 2
封装 DO-214AA
长度 4.32 mm
宽度 3.56 mm
高度 2.13 mm
封装 DO-214AA
工作温度 -65℃ ~ 175℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Power Management, 电源管理, 工业, Industrial
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MURS220T3G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
MURS220T3 安森美 | 完全替代 | MURS220T3G和MURS220T3的区别 |
STTH2R02U 意法半导体 | 功能相似 | MURS220T3G和STTH2R02U的区别 |
MURS120-E3/52T 威世 | 功能相似 | MURS220T3G和MURS120-E3/52T的区别 |
