16位微控制器 - MCU MCU 3/5V 48K I-temp Pb-free 80-LQFP
M16C/60 series IC 16 位 20MHz 48KB（48K x 8） 闪存 80-LQFP（12x12）
得捷:
IC MCU 16BIT 48KB FLASH 80LQFP
贸泽:
16位微控制器 - MCU MCU 3/5V 48K I-temp Pb-free 80-LQFP
艾睿:
Automate any process or system using this M30280F6HP#U3B microcontroller from Renesas. This microcontroller has an operating temperature range of -40 °C to 85 °C. It has a maximum clock speed of 20 MHz. Its ADC resolution is 10. This device has a typical operating supply voltage of 3.3|5 V. Its minimum operating supply voltage of 3 V, while its maximum is 5.5 V. This is a 16 bit processor. Its flash program memory is 48KB.
安富利:
MCU 16-bit R8C CISC 48KB Flash 3.3V/5V 80-Pin LQFP
Chip1Stop:
MCU 16-bit R8C CISC 48KB Flash 3.3V/5V Automotive 80-Pin LQFP
DeviceMart:
IC M16C MCU FLASH 48K 80LQFP
电源电压DC 5.00 V, 5.50 V max
时钟频率 20.0 MHz, 20.0 MHz max
RAM大小 4K x 8
位数 16
FLASH内存容量 48 KB
I/O引脚数 71
存取时间 20.0 µs
模数转换数ADC 1
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 300 mW
安装方式 Surface Mount
引脚数 80
封装 LQFP-80
封装 LQFP-80
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Unknown
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
