MAXIM INTEGRATED PRODUCTS MAX4416EUA+ 运算放大器, 轨至轨输出, 400 MHz, 2个放大器, 200 V/µs, 2.7V 至 5.5V, µMAX, 8 引脚
The is a low power, +3V/+5V, 400MHz single supply operational amplifier op-amp with rail to rail outputs in 8 pin µMAX package. This dual op-amp are unit gain stable and exhibit a common-mode input voltage range that extends from 100mV below ground to within 1.5V of the positive supply rail with a 200V/µs slew rate. Internal feedback around the output stage ensures low open-loop output impedance reducing gain sensitivity to load variations. This feedback also produces demand-driven current bias to the output transistors. The combination of high-speed, ultra low power, low distortion, excellent harmonic distortion and differential gain/phase performance makes op-amp ideal for low power/low voltage, high-speed portable systems.
供电电流 1.6 mA
电路数 2
通道数 2
针脚数 8
耗散功率 362 mW
共模抑制比 65 dB
带宽 400 MHz
转换速率 200 V/μs
增益频宽积 400 MHz
输入补偿电压 500 µV
输入偏置电流 1.3 µA
工作温度Max 85 ℃
工作温度Min -40 ℃
3dB带宽 400 MHz
耗散功率Max 362 mW
共模抑制比Min 65 dB
电源电压 2.7V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.7 V
安装方式 Surface Mount
引脚数 8
封装 TSSOP-8
长度 3.1 mm
宽度 3.1 mm
高度 0.95 mm
封装 TSSOP-8
工作温度 -40℃ ~ 85℃
产品生命周期 Unknown
包装方式 Each
制造应用 信号处理, Portable Devices, Signal Processing, Audio, 便携式器材, 音频
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MAX4416EUA+ Maxim Integrated 美信 | 当前型号 | 当前型号 |
MAX4416EUA+T 美信 | 完全替代 | MAX4416EUA+和MAX4416EUA+T的区别 |
MAX4416EUA 美信 | 类似代替 | MAX4416EUA+和MAX4416EUA的区别 |
MAX4416EUA-T 美信 | 类似代替 | MAX4416EUA+和MAX4416EUA-T的区别 |
