MC74HCT4066A: 四路模拟开关/多工器/信号分离器/带 LSTTL 兼容输入
The MC74HCT4066A utilizes silicon-gate CMOS technology to achieve fast progagation delays, low ON resistances, and low OFF-channel leakage current. This bilateral swithch, multiplexer, demultiplexer controls analog and digital voltages that may vary across the full power-supply range from VCC to GND. The HCT4066A is identical in pinout to the metal-gate CMOS MC14016 and MC14066. Each device has four independent switches. The device has been designed so the ON resistances RON are more linear over input voltage than RON of metal-gate CMOS analog switches. The ON and OFF control inputs are compatible with standard CMOS and LSTTL outputs. For analog switches with voltage-level translators, see the HC4316A.
Features
---
|
than the MC14016 or MC14066
无卤素状态 Halogen Free
电路数 4
通道数 4
耗散功率 500 mW
工作温度Max 125 ℃
工作温度Min -55 ℃
3dB带宽 150 MHz
耗散功率Max 500 mW
电源电压Max 5.5 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 14
封装 SOIC-14
封装 SOIC-14
工作温度 -55℃ ~ 125℃ TA
产品生命周期 Active
包装方式 Tube
制造应用 Audio, Video
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
