模拟多路复用器/多路解复用器高性能硅栅CMOS Analog Multiplexer/Demultiplexer High−Performance Silicon−Gate CMOS
Analog Multiplexer/Demultiplexer
High−Performance Silicon−Gate CMOS
The MC74LVX4051 utilizes silicon−gate CMOS technology to achieve fast propagation delays, low ON resistances, and low leakage currents. This analog multiplexer/demultiplexer controls analog voltages that may vary across the complete power supply range from VCC to VEE.
Features
•Fast Switching and Propagation Speeds
•Low Crosstalk Between Switches
•Analog Power Supply Range VCC− VEE = 3.0 V to 3.0 V
•Digital Control Power Supply Range VCC− GND = 2.5 to 6.0 V
•Improved Linearity and Lower ON Resistance Than Metal−Gate, HSL, or VHC Counterparts
•Low Noise
•Designed to Operate on a Single Supply with VEE= GND, or Using Split Supplies up to 3.0 V
•Break−Before−Make Circuitry
•Pb−Free Packages are Available- .
