MAX4020EEE+

MAXIM INTEGRATED PRODUCTS  MAX4020EEE+  运算放大器, 150 MHz, 4个放大器, 600 V/µs, 3.15V 至 11V, QSOP, 16 引脚

The is a high speed, single supply operational amplifier op-amp with rail to rail output in 16 pin QSOP package. This quad op-amp unity-gain stable device that combine high speed performance with rail to rail outputs. It operates from a 3.3V to 10V single supply or from ±1.65V to ±5V dual supplies. This voltage-feedback amplifier employ current-feedback technique to achieve 600V/µs slew rate and 150MHz bandwidth. The common-mode input voltage range extends beyond the negative power supply rail ground in single-supply applications. Excellent harmonic distortion and differential gain/phase performance makes this amplifier an ideal choice for a wide variety of signal processing applications.

.

Single 3.3V/5V operation & operating supply voltage range from 3.15V to 11V

.

Operating temperature range from -40°C to 85°C

.

Low-cost, 30MHz 0.1dB gain flatness & rise/fall time of 1ns

.

Slew rate of 600V/µs, CMRR of 100dB

.

Input common-mode range extends beyond VEE

.

Low differential gain/phase of 0.02%/0.02°

.

Low distortion at 5MHz, -78dBc SFDR & -75dB total harmonic distortion

.

High output drive of ±120mA

.

Output short-circuit current is ±150mA
