双向 28.2V
45.7V 夹子 13.2A Ipp TVS - 通孔 DO-15
得捷:
TVS DIODE 28.2VWM 45.7VC DO15
立创商城:
双向 Vrwm:28.2V 600W
贸泽:
ESD Suppressors / TVS Diodes BI-DIR 600W 13.2A
艾睿:
Do not risk expensive equipment and machinery from surges with this P6KE33CA-TP TVS diode from Micro Commercial Components. This device&s;s maximum clamping voltage is 45.7 V and minimum breakdown voltage is 31.4 V. Its test current is 1 mA. Its peak pulse power dissipation is 600 W. Its maximum leakage current is 1 μA. This TVS diode has a minimum operating temperature of -55 °C and a maximum of 175 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment.
Verical:
TVS Diode Single Bi-Dir 28.2V 600W Automotive 2-Pin DO-15 T/R
额定电压DC 33.0 V
额定功率 600 W
击穿电压 33 V
耗散功率 600 W
钳位电压 45.7 V
最大反向电压(Vrrm) 28.2V
测试电流 1 mA
脉冲峰值功率 600 W
最小反向击穿电压 31.4 V
击穿电压 31.4 V
工作温度Max 175 ℃
工作温度Min -55 ℃
安装方式 Through Hole
引脚数 2
封装 DO-15
长度 7.60 mm
直径 3.60 mm
封装 DO-15
工作温度 -55℃ ~ 175℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
P6KE33CA-TP Micro Commercial Components 美微科 | 当前型号 | 当前型号 |
P6KE33CA 力特 | 完全替代 | P6KE33CA-TP和P6KE33CA的区别 |
P6KE33CA-B 力特 | 类似代替 | P6KE33CA-TP和P6KE33CA-B的区别 |
