BOURNS JW MILLER PM13560S-100M-RC 电感, SMD, 10uH, 12A, 20%
10 µH 屏蔽 鼓芯,绕线式 器 9 A 25.5 毫欧最大 非标准
得捷:
FIXED IND 10UH 9A 25.5 MOHM SMD
立创商城:
10uH ±20% 9A 25.5mΩ
贸泽:
Fixed Inductors 10uH 20%
e络盟:
电感, 屏蔽, 10UH, 16A, SMD
艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this power PM13560S-100M-RC surface mount inductor from Bourns is perfect for you! This SMD inductor has an operating temperature range of -55 °C to 150 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This product is 13.9 mm long, 5.9 mm tall and 13.5 mm deep. This SMD inductor has a maximum DC current of 9 A with a maximum resistance of 25.5m Ohm. This device utilizes wirewound technology. Its test frequency is 100K Hz. It has a tolerance of 20%. It has an inductance of 10u H.
Allied Electronics:
Choke, Pwr, Shielded; 10 LuH; DCR 25.5 Ohm Max
安富利:
Ind Power Shielded Wirewound 10uH 20% 100KHz 9A T/R
Chip1Stop:
Inductor Power Shielded Wirewound 10uH 20% 100KHz Iron 9A 25.5mOhm DCR T/R
Verical:
Inductor Power Shielded Wirewound 10uH 20% 100KHz Iron 9A 0.0255Ohm DCR T/R
Newark:
# BOURNS JW MILLER PM13560S-100M-RC Surface Mount Power Inductor, PM13560S Series, 10 µH, 9 A, 16 A, Shielded, 0.0255 ohm
MASTER:
Inductor Power Shielded Wirewound 10uH 20% 100KHz Iron 9A 25.5mOhm DCR T/R
Electro Sonic:
Inductor Power Shielded Wirewound 10uH 20% 100KHz Iron 9A 25.5mOhm DCR T/R
额定电流 9 A
容差 ±20 %
电感 10 µH
屏蔽 Yes
电感公差 ±20 %
测试频率 100 kHz
电阻DC) ≤25.5 mΩ
工作温度Max 150 ℃
工作温度Min -55 ℃
电阻DC Max 0.0255 Ω
安装方式 Surface Mount
引脚数 2
封装 13.9mm x 13.5mm x 5.9mm
长度 13.9 mm
宽度 13.5 mm
高度 5.2 mm
封装 13.9mm x 13.5mm x 5.9mm
工作温度 -55℃ ~ 150℃
产品生命周期 Not Recommended
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
HTS代码 8504508000
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
PM13560S-100M-RC Bourns J.W. Miller 伯恩斯 | 当前型号 | 当前型号 |
SRP1250-100M 伯恩斯 | 完全替代 | PM13560S-100M-RC和SRP1250-100M的区别 |
PM13560S-100M 伯恩斯 | 功能相似 | PM13560S-100M-RC和PM13560S-100M的区别 |
