74LV 系列,Texas Instruments低电压 CMOS 逻辑 工作电压:2 - 5.5 兼容性:输入 LVTTL/TTL、输出 LVCMOS ### 74LV 系列
74LV 系列,Texas Instruments
低电压 CMOS 逻辑
工作电压:2 - 5.5
兼容性:输入 LVTTL/TTL、输出 LVCMOS
得捷:
IC D-TYPE LATCH OCT 3-ST 20TSSOP
立创商城:
SN74LV373APWR
德州仪器TI:
Octal Transparent D-Type Latches With 3-State Outputs
欧时:
### 74LV 系列,Texas Instruments低电压 CMOS 逻辑 工作电压:2 - 5.5 兼容性:输入 LVTTL/TTL、输出 LVCMOS ### 74LV 系列
贸泽:
闭锁 Tri-St Octal D-Type
艾睿:
Say goodbye to real time information seeping through logic gates by using this d-type SN74LV373APWR low-level latch from Texas Instruments. With a 3-state output, this is power management at its best. This latch has an operating temperature range of -40 °C to 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. It has 8 channels per chip. This non-inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 5.5 V.
安富利:
Latch Transparent 3-ST 8-CH D-Type 20-Pin TSSOP T/R
Chip1Stop:
Latch Transparent 3-ST 8-CH D-Type 20-Pin TSSOP T/R
Verical:
Latch Transparent 3-ST 8-CH D-Type 20-Pin TSSOP T/R
Newark:
# TEXAS INSTRUMENTS SN74LV373APWR Latch, 74LV373, Transparent, Tri State, 10.5 ns, 16 mA, TSSOP
Win Source:
D-Type Transparent Latch 1 Channel 8:8 IC Tri-State 20-TSSOP
DeviceMart:
IC D-TYPE LATCH OCT 3-ST 20TSSOP
电源电压DC 2.00V ~ 5.50V
输出接口数 8
输出电流 16 mA
电路数 8
通道数 8
位数 8
极性 Non-Inverting
电压波节 5.00 V, 3.30 V, 2.50 V
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 20
封装 TSSOP-20
长度 6.5 mm
宽度 4.4 mm
高度 1.15 mm
封装 TSSOP-20
重量 0.0012319569584 kg
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
香港进出口证 NLR
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LV373APWR TI 德州仪器 | 当前型号 | 当前型号 |
SN74LV373APWT 德州仪器 | 完全替代 | SN74LV373APWR和SN74LV373APWT的区别 |
SN74LV373APW 德州仪器 | 类似代替 | SN74LV373APWR和SN74LV373APW的区别 |
SN74LV373ATPWR 德州仪器 | 类似代替 | SN74LV373APWR和SN74LV373ATPWR的区别 |
