74 ACT 系列,缓冲器/驱动器,Texas Instrument高级 CMOS 逻辑 工作电压:4.5 至 5.5 兼容性:输入 TTL、输出 CMOS ### 74ACT 系列
74 ACT 系列,缓冲器/驱动器,Texas Instrument
高级 CMOS 逻辑
工作电压:4.5 至 5.5
兼容性:输入 TTL、输出 CMOS
### 74ACT 系列
得捷:
IC BUF NON-INVERT 5.5V 20TSSOP
欧时:
Texas Instruments SN74ACT241PW ACT 系列 8位 三态 非反相 缓冲器,驱动器, 20引脚 TSSOP封装
立创商城:
SN74ACT241PW
德州仪器TI:
8-ch, 4.5-V to 5.5-V buffers with TTL-compatible CMOS inputs and 3-state outputs
贸泽:
缓冲器和线路驱动器 Octal Buffer/Driver With 3-State Outputs
e络盟:
缓冲器/驱动器, 74ACT241, 4.5V至5.5V, TSSOP-20
艾睿:
By driving the input to the transmission line this SN74ACT241PW buffer and line driver by Texas Instruments will amplify any signal. With a 3-state output, this is power management at its best. This line driver has a minimum operating temperature of -40 °C and a maximum of 85 °C. This device comes in tube packaging. It has 8 channels per chip. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V.
安富利:
Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin TSSOP Tube
Chip1Stop:
Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin TSSOP Tube
Verical:
Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin TSSOP Tube
Win Source:
IC BUF NON-INVERT 5.5V 20TSSOP / Buffer, Non-Inverting 2 Element 4 Bit per Element 3-State Output 20-TSSOP
电源电压DC 4.50V ~ 5.50V
输出接口数 8
通道数 8
针脚数 20
位数 8
传送延迟时间 9.50 ns
电压波节 5.00 V
输出电流驱动 -1.00 mA
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 20
封装 TSSOP-20
长度 6.6 mm
宽度 4.5 mm
高度 1.05 mm
封装 TSSOP-20
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Each
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74ACT241PW TI 德州仪器 | 当前型号 | 当前型号 |
SN74ACT241PWR 德州仪器 | 完全替代 | SN74ACT241PW和SN74ACT241PWR的区别 |
SN74ACT241PWRG4 德州仪器 | 完全替代 | SN74ACT241PW和SN74ACT241PWRG4的区别 |
74LVC2G126DCTRG4 德州仪器 | 功能相似 | SN74ACT241PW和74LVC2G126DCTRG4的区别 |
