74LV 系列,Texas Instruments低电压 CMOS 逻辑 工作电压:2 - 5.5 兼容性:输入 LVTTL/TTL、输出 LVCMOS ### 74LV 系列
74LV 系列,Texas Instruments
低电压 CMOS 逻辑
工作电压:2 - 5.5
兼容性:输入 LVTTL/TTL、输出 LVCMOS
### 74LV 系列
立创商城:
SN74LV74ARGYR
德州仪器TI:
Dual Positive-Edge-Triggered D-Type Flip-Flops
得捷:
IC FF D-TYPE DUAL 1BIT 14VQFN
欧时:
Texas Instruments SN74LV74ARGYR 双 触发器 IC, 差分输出, 2 → 5.5 V电源, 14引脚 QFN封装
贸泽:
Flip Flops Dual
艾睿:
Texas Instruments&s; SN74LV74ARGYR flip flop device will allow you to easily build and test a circuit based on the state information provided. It has a differential output signal. This flip flop has a minimum operating temperature of -40 °C and a maximum of 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This inverting/non-inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 5.5 V. It has 2 channels per chip.
安富利:
Flip Flop D-Type Pos-Edge 2-Element 14-Pin VQFN EP T/R
Chip1Stop:
Flip Flop D-Type Pos-Edge 2-Element 14-Pin VQFN EP T/R
Verical:
Flip Flop D-Type Pos-Edge 2-Element 14-Pin VQFN EP T/R
Newark:
# TEXAS INSTRUMENTS SN74LV74ARGYR Flip-Flop, Complementary, Differential, Positive Edge, 74LV74, D, 7.2 ns, 110 MHz, 12 mA, QFN
频率 110 MHz
电源电压DC 5.00 V, 5.50 V max
输出接口数 1
输出电流 12 mA
电路数 2
通道数 2
时钟频率 140 MHz
位数 2
极性 Non-Inverting, Inverting
电压波节 5.00 V, 3.30 V, 2.50 V
输入电容 2 pF
输入数 1
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 14
封装 VQFN-14
长度 3.5 mm
宽度 3.5 mm
高度 0.9 mm
封装 VQFN-14
工作温度 -40℃ ~ 125℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LV74ARGYR TI 德州仪器 | 当前型号 | 当前型号 |
SN74LV74ARGYRG4 德州仪器 | 功能相似 | SN74LV74ARGYR和SN74LV74ARGYRG4的区别 |
5962-8405601VDA 德州仪器 | 功能相似 | SN74LV74ARGYR和5962-8405601VDA的区别 |
JM38510/65302BDA 德州仪器 | 功能相似 | SN74LV74ARGYR和JM38510/65302BDA的区别 |
