SNJ54ACT00J

四路2输入正与非门 QUADRUPLE 2-INPUT POSITIVE-NAND GATES

description/ordering information

The ‘ACT00 devices contain four independent 2-input NAND gates. Each gate performs the Boolean function of Y = A • B or Y = A + B in positive logic.

• 4.5-V to 5.5-V VCC Operation

• Inputs Accept Voltages to 5.5 V

• Max tpd of 8 ns at 5 V

• Inputs Are TTL-Voltage Compatible

立创商城:
SNJ54ACT00J

德州仪器TI:
Military 4-ch, 2-input, 4.5-V to 5.5-V NAND gates with TTL-compatible CMOS inputs

艾睿:
NAND Gate 4-Element 2-IN CMOS 14-Pin CDIP Tube

安富利:
NAND Gate 4-Element 2-IN CMOS 14-Pin CDIP Tube

Chip1Stop:
NAND Gate 4-Element 2-IN CMOS 14-Pin CDIP Tube

Verical:
NAND Gate 4-Element 2-IN CMOS 14-Pin CDIP Tube

Win Source:
54ACT00 QUADRUPLE 2-INPUT POSITI / IC Channel
