SLS-15-060T

SLS-15-060T图片1
SLS-15-060T图片2
SLS-15-060T图片3
SLS-15-060T概述

Power Supply; AC-DC; 15V; 6A; 100-240Vin; Open Frame; Pnl Mnt; Linear; Silverline Series

**Silverline Series

Features and Benefits:

* **Easy-to-install screw terminal connections

* Cover options

* Industry standard footprint

* Automatic resetting overload protection

* Short circuit protected

* Fast transient response

* Tight Regulation: 0.10% Line and Load Combined

* No Soldering Required

* Terminal Block Connection

* Built-In OVP on 5 V Models Optional on 12 V, 15 V, 24 V

* Foldback Current Limiting

* Form, Fit, Function Replacements for Most Major Manufacturers

* UL Recognized, CSA Approval

* Input Voltage: 100/120/220/230/240 AC Selectable

* Input Frequency: 47-63 Hz

* Remote Sensing

* Operating Temperature: 0° to +50°C

* EMI/RFI Meets FCC Class B and VDE 0871 for Class B

* Shock Vibration Per Mil-STD-810C

SLS-15-060T中文资料参数规格
技术参数

频率 47Hz ~ 63Hz

额定电流 6 A

输出接口数 1

输出电压 15 VDC

输出电流 6 A

输出功率 90 W

输入电压AC Max 240 v

输入电压AC Min 100 v

输出功率Max 90 W

输入电压 100VAC ~ 240VAC

物理参数

工作温度 0℃ ~ 50℃

其他

产品生命周期 Not For New Designs

符合标准

RoHS标准 RoHS Compliant

数据手册

在线购买SLS-15-060T
型号: SLS-15-060T
制造商: SolaHD
描述:Power Supply; AC-DC; 15V; 6A; 100-240Vin; Open Frame; Pnl Mnt; Linear; Silverline Series
