Conn Socket Strip SKT 10POS 2.54mm Solder ST SMD T/R
10 Position Receptacle, Pass Through Connector 0.100" 2.54mm Surface Mount Gold
得捷:
CONN RCPT 10POS 0.1 GOLD SMD
欧时:
.100" 2.54 mm Tiger Claw Surface Mount
立创商城:
SSM-105-L-DV-K-TR
艾睿:
Are you looking for a solution to support physical configuration options on your PCB? Then mount this socket strip SSM-105-L-DV-K-TR header connector from Samtec on your PCB today! This SKT connector&s;s 10 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 510 VDC|360VAC. It has a socket type gender. This is a 2-row connector. Its pitch is 2.54 mm. It has a straight body orientation. This device has a maximum current rating of 5.2 A/contact. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. It uses the solder termination method. This product is 12.7 mm long, 7.37 mm tall and 7.04 mm deep. SSM-105-L-DV-K-TR is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C.
安富利:
Conn Socket Strip SKT 10 POS 2.54mm Solder ST SMD T/R
Newark:
# SAMTEC SSM-105-L-DV-K-TR Board-To-Board Connector, 2.54 mm, 10 Contacts, Receptacle, SSM Series, Surface Mount, 2 Rows
触点数 10
极性 Female
触点电镀 Gold
额定电流 3.00 A
排数 2
针脚数 10
接触电阻 10.0 mΩ
额定电流Max 5.2A/触头
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 405VAC, 572VDC
接触电阻Max 10 mΩ
安装方式 Surface Mount
封装 -
高度 7.37 mm
封装 -
外壳颜色 Black
颜色 Black
触点材质 Phosphor Bronze
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SSM-105-L-DV-K-TR Samtec 申泰电子 | 当前型号 | 当前型号 |
SSM-105-S-DV-K-TR 申泰电子 | 完全替代 | SSM-105-L-DV-K-TR和SSM-105-S-DV-K-TR的区别 |
SSM-105-L-DV 申泰电子 | 功能相似 | SSM-105-L-DV-K-TR和SSM-105-L-DV的区别 |
SSM-105-L-DV-TR 申泰电子 | 功能相似 | SSM-105-L-DV-K-TR和SSM-105-L-DV-TR的区别 |
