1.9 mm 25° 无色 透明 250 mcd 2 V 表面贴装 LED
指示 - 分立
得捷:
LED 2X2.5MM 590SYW CLR ZBEND T/R
艾睿:
LED Uni-Color Yellow 590nm 2-Pin SMD T/R
Allied Electronics:
LED; Super Yellow; 90 mcd; 2.1 V Typ.Forward; Surface; Axial Leaded; 590 nm
富昌:
超级 黄色 1.9 mm 25° 无色 透明 250 mcd 2 V 表面贴装 LED
Verical:
LED Uni-Color Yellow 590nm 2-Pin SMD T/R
Newark:
# LUMEX SSL-LXA228SYC-TR31 LED, QuasarBrite, Yellow, SMD, 1.9mm, 20 mA, 2 V, 590 nm
MASTER:
LED Uni-Color Yellow 590nm 2-Pin SMD T/R
Online Components:
LED Uni-Color Yellow 590nm 2-Pin SMD T/R
Electro Sonic:
LED Uni-Color Yellow 590nm 2-Pin SMD T/R
正向电压 2 V
波长 590 nm
发光强度 250 mcd
视角 25°
峰值波长 590 nm
耗散功率 100 W
测试电流 20 mA
正向电流 20 mA
正向电压Max 2.5 V
正向电流Max 30 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 100 mW
额定电压 2.1 V
安装方式 Surface Mount
引脚数 2
封装 SMD
高度 2.8 mm
封装 SMD
颜色 Yellow
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SSL-LXA228SYC-TR31 Lumex 鲁美科思 | 当前型号 | 当前型号 |
SSL-LXA228SYC-TR11 鲁美科思 | 功能相似 | SSL-LXA228SYC-TR31和SSL-LXA228SYC-TR11的区别 |
SSL-LXA228SYC 鲁美科思 | 功能相似 | SSL-LXA228SYC-TR31和SSL-LXA228SYC的区别 |
SSL-LXA228SYC-TR21 鲁美科思 | 功能相似 | SSL-LXA228SYC-TR31和SSL-LXA228SYC-TR21的区别 |
