DUAL外设驱动程序 DUAL PERIPHERAL DRIVERS
PERIPHERAL DRIVERS FOR HIGH-VOLTAGE HIGH-CURRENT DRIVER APPLICAONS
description
Series SN75471 dual peripheral drivers are functionally interchangeable with series SN75451B and series SN75461 peripheral drivers, but are designed for use in systems that require higher breakdown voltages than either of those series can provide at the expense of slightly slower switching speeds than series 75451B limits are the same as series SN75461. Typical applications include high-speed logic buffers, power drivers, relay drivers, lamp drivers, MOS drivers, line drivers, and memory drivers.
Characterized for Use to 300 mA
High-Voltage Outputs
No Output Latch-Up at 55 V After Conducting 300 mA
Medium-Speed Switching
Circuit Flexibility for Varied Applications and Choice of Logic Function
TTL-Compatible Diode-Clamped Inputs
Standard Supply Voltages
Plastic DIP P With Copper Lead Frame Provides Cooler Operation and Improved Reliability
