TCLAMP 系列 29 V 25 pF 表面贴装 低电容 TVS - SLP-2626P10
29V Clamp 95A 8/20µs Ipp Tvs Diode Surface Mount SLP2626P10 2.6x2.6
得捷:
TVS DIODE 6VWM 29VC SLP2626P10
立创商城:
Vrwm:6V@Max 2.5kW
贸泽:
ESD 抑制器/TVS 二极管 LOW CAP TVS & TELCOM INTERFACE
艾睿:
Are you a designer worried about electrostatic discharge? Do not risk it, add this diode array TCLAMP0602N.TCT ESD protection device from Semtech. This ESD diode has a maximum ESD protection device voltage of 30@Air Gap/30@Contact Disc kV. This device&s;s maximum clamping voltage is 29 V. This ESD diode has an operating temperature range of -55 °C to 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It is made in a dual configuration.
安富利:
ESD Suppressor TVS 30KV 10-Pin SLP EP T/R
富昌:
TCLAMP0602N 系列 29 Vcl 25 pF 表面贴装 低电容 TVS 阵列 - SLP-10
Chip1Stop:
ESD Suppressor Diode Arrays 30KV 10-Pin SLP EP T/R
Verical:
ESD Suppressor Diode Diode Array Uni-Dir 6V 10-Pin SLP EP T/R
Newark:
# SEMTECH TCLAMP0602N.TCT ESD Protection Device, 29 V, SLP2626P10, 10 Pins, 6 V, 2.5 kW
Win Source:
TVS DIODE 6VWM 29VC 10SLP
额定电压DC 6.00 V
工作电压 6 V
额定功率 2.50 kW
耗散功率 2.5 kW
钳位电压 29 V
测试电流 1 mA
脉冲峰值功率 2500 W
最小反向击穿电压 6.8 V
击穿电压 6.8 V
工作温度Max 125 ℃
工作温度Min -55 ℃
安装方式 Surface Mount
引脚数 10
封装 UFDFN-10
长度 2.60 mm
宽度 2.60 mm
高度 0.57 mm
封装 UFDFN-10
工作温度 -55℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 以太网,电信
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TCLAMP0602N.TCT Semtech Corporation | 当前型号 | 当前型号 |
JANTXV1N6138AUS Semtech Corporation | 功能相似 | TCLAMP0602N.TCT和JANTXV1N6138AUS的区别 |
JANTX1N6138AUS Semtech Corporation | 功能相似 | TCLAMP0602N.TCT和JANTX1N6138AUS的区别 |
JANTXV1N6138US Semtech Corporation | 功能相似 | TCLAMP0602N.TCT和JANTXV1N6138US的区别 |
