THAT1646P08-U

THAT CORPORATION  THAT1646P08-U  差分线形驱动器, 单片, 1 驱动器

The 1646P08-U is a balanced Line Driver IC monolithic audio differential line drivers offering improved performance over conventional cross coupled designs. Based on a high-performance, fully differential operational amplifier and laser-trimmed thin-film resistors, both families exhibit-bit low noise and distortion, high slew rate and wide output swing. The parts are stable when driving difficult loads and have short-circuit protected outputs. Designed from the ground up in complementary dielectric isolation process, both models incorporate THATs patented OutSmarts1 technology. This is a dual feedback-loop design that prevents the excessive ground currents typical of cross-coupled output stages CCOS when clipping into single-ended loads. OutSmarts uses two individual negative-feedback loops to separately control the differential output voltage and common mode output currents, making the designs inherently more stable and less sensitive to component tolerances than common CCOSes.

.

Balanced, transformer-like floating output

.

OutSmarts® technology improves clipping into single-ended loads

.

Stable driving long cables and capacitive loads

.

Industry standard pinout
