TDA8551T/N1

NXP  TDA8551T/N1  音频功率放大器, AB, 1通道, 1.4 W, 2.7V 至 5.5V, SOIC, 8 引脚

The is a 1-channel 1W BTL Audio Amplifier with digital volume control. The amplifier with capable of delivering 1W output power to an 8R load at THD = 10% using a 5V power supply. The circuit contains a BTL power amplifier, a digital volume control and standby/mute logic.

.

One pin digital volume control

.

Volume setting with UP/DOWN pulses

.

Flexibility in use

.

Few external components

.

Low saturation voltage of output stage

.

Standby mode controlled by CMOS compatible levels

.

Low standby current

.

No switch-ON/switch-OFF plops

.

High supply voltage ripple rejection
