Trans Voltage Suppressor Diode, 600W, 40.2V VRWM, Bidirectional, 1Element, Silicon, DO-15, ROHS COMPLIANT, PLASTIC PACKAGE-2
64.8V 夹子 9.3A Ipp TVS - 通孔 DO-15
得捷:
TVS DIODE 40.2VWM 64.8VC DO15
立创商城:
Vrwm:40.2V 600W
艾睿:
Protect your electronic equipment from sudden or momentary overvoltage conditions with this P6KE47CA-TP TVS diode from Micro Commercial Components. Its maximum leakage current is 1 μA. This device&s;s maximum clamping voltage is 64.8 V and minimum breakdown voltage is 44.7 V. Its peak pulse power dissipation is 600 W. Its test current is 1 mA. This TVS diode has a minimum operating temperature of -55 °C and a maximum of 175 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components.
Chip1Stop:
Diode TVS Single Bi-Dir 40.2V 600W 2-Pin DO-15 T/R
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
P6KE47CA-TP Micro Commercial Components 美微科 | 当前型号 | 当前型号 |
P6KE47CA 台湾半导体 | 类似代替 | P6KE47CA-TP和P6KE47CA的区别 |
P6KE47CARL 意法半导体 | 功能相似 | P6KE47CA-TP和P6KE47CARL的区别 |
