PM7232S-R72M-RC

屏蔽式功率电感器 Shielded Power Inductors

* Formerly model * Shielded construction * Unit height of 3.2 mm * Inductance range: 0.1 µH to 1.5 µH * Current up to 32.5 A * RoHS compliant

得捷:
FIXED IND 720NH 15.5A 5.5MOHM SM

艾睿:
Use this power PM7232S-R72M-RC surface mount inductor from Bourns to make any circuit look clean and compact. This SMD inductor has a minimum operating temperature of -55 °C and a maximum of 150 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. It has a tolerance of 20%. This SMD inductor has a maximum DC current of 15.5 A with a maximum resistance of 5.5m Ohm. It has an inductance of 720n H. This product is 7.8 mm long, 3.9 mm tall and 7 mm deep. This device is made with wirewound technology. Its test frequency is 100K Hz.

安富利:
Ind Power Shielded Wirewound 720nH 20% 100KHz Iron 20A T/R

Chip1Stop:
Ind Power Shielded Wirewound 720nH 20% 100KHz Iron 15.5A T/R

Newark:
# BOURNS JW MILLER  PM7232S-R72M-RC  Surface Mount Power Inductor, PM7232S Series, 720 nH, 15.5 A, 20 A, Shielded, 5500 µohm

Electro Sonic:
Inductor Power Shielded Wirewound 720nH 20% 100KHz Iron 15.5A 5.5mOhm DCR T/R
