9767037 Analogue Positive Press Gauge Bottom Entry 15psi, Connection Size 1/4 NPT
* 304 SS Case
* Copper Alloy Wetted Parts
* Lower Mount
* Polycarbonate Window with Buna-N Gasket
* SS, Crimped Window Ring
* White Aluminum Dial
* Black Aluminum Pointer
* Ambient Operating Temperature Glycerine Filled: –4°F to +140°F –20°C to +60°C
* Accuracy: ±2/1/2% of Span ASME B40.100 Grade A
**Applications:**
* Intended for Adverse Service Conditions Where Pulsating or Vibration Exists with Liquid Filling
* Hydraulics and Compressors
* Suitable for Gaseous or Liquid Media That Will Not Obstruct the Pressure System
Brand/Series 213.53 Series
Connecting Thread 1/4 NPT
Diameter 2.5 "
Fluid Type Gaseous, Liquid Media
Gauge Range 15 PSI
Material 304 Stainless Steel Case, Black Aluminum Pointer, Copper Alloy Wetted Part, Polycarbonate Window, Stainless Steel Polished Ring, White Aluminum Dial
Mounting Orientation Lower
Mounting Type Lower Mount
Type Analog
