37321000410

Electric Fuse, Fast Blow, 10A, 250VAC, 50A IR, Through Hole, TR5, HALOGEN FREE AND ROHS COMPLIANT

** 373 Series TR5 Fast Acting Fuses**

The TR5 373 series from littelfuse are a range of fast acting 250V fuses. The 373 series of fuse are designed to be used in applications such as battery chargers, power supplies, industrial controllers and consumer electronics.

艾睿:
Be protected by adding a subminiature 37321000410 fuse developed by Littelfuse. This device has a current rating of 10. This device has a maximum power dissipation of 2 W. Its maximum power dissipation is 2 W. This fuse has an operating temperature range of -40 °C to 85 °C. It has 2 terminals. The 37321000410 fuse has a radial termination style. This product comes packaged in bulk, so the parts will be stored loosely. The maximum AC voltage rating is 250 VAC. Its fuse is made from thermoplastic. This product is 8Max mm tall with a diameter of 8.5 mm.

Allied Electronics:
Fuse; TR5; Fast-Acting; Thermoplastic; 10A; 250V; Short Radial Leads; PCB Mount

Chip1Stop:
Fuse Subminiature Fast Acting 10A 250V Radial 8.5 X 8mm Thermoplastic Bulk

Verical:
Fuse Subminiature Fast Acting 10A 250V Radial 8.5 X 8mm Thermoplastic Bulk UL
