372 系列 延时 250 V 2.5 A 8.5 x 8 mm TR5® 径向引线 保险丝
2.5A 250V AC DC Fuse Board Mount Cartridge Style Excluded Through Hole Radial, Can, Vertical
立创商城:
250VAC 2.5A 惯性保险丝
得捷:
FUSE BOARD MOUNT 2.5A 250VAC RAD
艾睿:
A great alternative to a circuit breaker, this a subminiature 37212500001 fuse from Littelfuse will protect your electronics. This device has a current rating of 2.5. Its maximum power dissipation is 0.7 W. This device has a maximum power dissipation of 0.7 W. This fuse has a minimum operating temperature of -40 °C and a maximum of 85 °C. It has 2 terminals. The 37212500001 fuse has a radial termination style. This product is 8Max mm tall with a diameter of 8.5 mm. The maximum AC voltage rating is 250 VAC.
富昌:
372 系列 延时 250 V 2.5 A 8.5 x 8 mm TR5® 径向引线 保险丝
Verical:
Fuse Subminiature Slow Blow Acting 2.5A 250V Radial 8.5 X 8mm Polyamide 66 Ammo CCC/CQC/KC/SEMKO/UL/VDE/cULus
儒卓力:
**2,5A 250V slow TR5 IEC long **
额定电压DC 250 V
额定电压AC 250 V
额定电流 2.5 A
易燃性等级 UL 94 V-0
耗散功率 0.7 W
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 0.7 W
额定电压 250 V
额定电压AC Max 250 V
安装方式 Through Hole
引脚数 2
封装 Radial, CAN
长度 8 mm
高度 8 mm
直径 8.50 mm
封装 Radial, CAN
颜色 Brown
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
