37211600431

Electric Fuse, Time Lag Blow, 1.6A, 250VAC, 35A IR, Through Hole, TR5, HALOGEN FREE AND ROHS COMPLIANT

The 372 series from Littlefuse are TR5, sub miniature time lag radial leaded fuses. The fuses can be either soldered directly into a printed circuit board or can be plugged into a two pin socket. The 370 series fuses are designed in accordance to IEC 60127-3 standards.

.

Rated voltage of 250VAC

.

Current rating range from 40mA to 6.3A

.

Reduced PCB space requirements

.

UL, VDE, PSE/JET, CCC approved

.

Low internal resistance

.

Shock safe casing

.

Vibration resistant

.

Available in 35A, 40A, 50A breaking capacity

.

Operating temperature range from -40°C to 85°C
