信号继电器, 5 VDC, SPDT, 1 A, P1/V23026系列, 通孔安装, 闭锁双线圈
The is a Signal Relay with SPDT-CO gold-rhodium-plated palladium nickel bifurcated contact. This P1/V23026-series PCB mount signal relay is directly triggerable with TTL standard modules as ALS, HCT and ACT. Latching dual coil, bistable polarized magnetic system, solder through hole terminals and 390R coil resistance.
- .
- Immersion cleanable
- .
- 80mW Coil power
- .
- 1500Vrms Dielectric strength between contact and coil
- .
- -40 to 85°C Operating temperature range
额定电压DC 125 V
额定电压AC 150 V
触点类型 SPDT
触点额定电流 1 A
线圈电压 5 VDC
线圈电流 12.82 mA
线圈功率DC 65.0 mW
线圈电阻 390 Ω
载流 500 mA
额定电流Max 1 A
线圈电压DC 5 V
线圈功率 64 mW
额定功率Max 30W, 60VA
开关电流Max 1 A
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压DC Max 125 V
额定电压AC Max 150 V
安装方式 Through Hole
引脚数 6
封装 DIP
长度 13 mm
宽度 7.6 mm
高度 6.9 mm
封装 DIP
工作温度 -40℃ ~ 85℃
产品生命周期 Unknown
包装方式 Tube
制造应用 工业, Industrial, 医用, 车用, Medical, Test & Measurement, Automotive, Safety, 测试与测量, 安全
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536410050
