312100002概述

Switch Thumb-Pushwheel Thumbwheel BCD 10 0.1A 120VAC 28VDC PC Board Panel Mount

**Features:**

* Most complete product offering in the industry

* Spacers available to fit most panel cutouts

* Front or rear mounting options

**Typical Applications:**

* Test & measurement equipment

* Industrial equipment

* Computer devices


立创商城:
312100002


艾睿:
Switch Thumb-Pushwheel Thumbwheel BCD 10 0.1A 120VAC 28VDC PC Board Panel Mount


Allied Electronics:
Switch, Thumbwheel, 10 position, 1 Switch Section, BCD, Snap-In, Front Mount


Chip1Stop:
Switch Thumb-Pushwheel Thumbwheel BCD 10 0.1A 120VAC 28VDC PC Board Panel Mount


Verical:
Switch Thumb-Pushwheel Thumbwheel BCD 10 0.1A 120VAC 28VDC PC Board Panel Mount


MASTER:
Thumbwheel Switch


Online Components:
Thumbwheel Switch


Electro Sonic:
Thumbwheel Switch


312100002中文资料参数规格
技术参数

额定电流 100 mA

针脚数 10

额定电流Max 0.1 A

工作温度Max 65 ℃

工作温度Min -40 ℃

额定电压 120 VAC

额定电压DC Max 28 V

额定电压AC Max 120 V

接触电阻Max 100 mΩ

封装参数

安装方式 Panel, Snap-In, Solder

封装 -

外形尺寸

封装 -

物理参数

颜色 Black

工作温度 -40℃ ~ 65℃

其他

产品生命周期 Active

包装方式 Bulk

符合标准

RoHS标准 RoHS Compliant

海关信息

ECCN代码 EAR99

HTS代码 8536509065

数据手册

在线购买312100002
型号: 312100002
制造商: C&K Components
描述:Switch Thumb-Pushwheel Thumbwheel BCD 10 0.1A 120VAC 28VDC PC Board Panel Mount
