3SMAJ5931B-TP

MICRO COMMERCIAL COMPONENTS  3SMAJ5931B-TP  齐纳二极管, 3W, 18V, DO-214AC

- 齐纳 18 V 3 W ±5% 表面贴装型 DO-214AC（SMA）

得捷:
DIODE ZENER 18V 3W DO214AC

立创商城:
18V 3W

贸泽:
稳压二极管 3W 18V

e络盟:
齐纳二极管, 3W, 18V, DO-214AC

艾睿:
If your circuit requires a diode to operate in the reverse breakdown region, then this 3SMAJ5931B-TP zener diode from Micro Commercial Components is exactly what you need. Its maximum power dissipation is 3000 mW. Its test current is 20.8 mA. This device has a maximum regulator current of 166 mA. Its maximum leakage current is 1 μA. This product will be shipped in tape and reel packaging so that components can be mounted effectively. It is made in a single configuration. This zener diode has a minimum operating temperature of -55 °C and a maximum of 150 °C. This zener device has a nominal voltage of 18 V and a voltage tolerance of 5%.

Chip1Stop:
Diode Zener Single 18V 5% 3W 2-Pin SMA T/R

Verical:
Zener Diode Single 18V 5% 12Ohm 3000mW 2-Pin SMA T/R

Newark:
# MICRO COMMERCIAL COMPONENTS  3SMAJ5931B-TP  Zener Single Diode, 18 V, 3 W, DO-214AC, 5 %, 2 Pins, 150 °C
