MICRO COMMERCIAL COMPONENTS 3SMAJ5927B-TP 齐纳二极管, 3W, 12V, DO-214AC
- 齐纳 ±5% 表面贴装型 DO-214AC(SMA)
得捷:
DIODE ZENER 12V 3W DO214AC
立创商城:
12V 3W
e络盟:
齐纳二极管, 3W, 12V, DO-214AC, 整卷
艾睿:
This 3SMAJ5927B-TP zener diode from Micro Commercial Components will allow you to run it in the reverse direction. Its maximum power dissipation is 3000 mW. This device has a maximum regulator current of 250 mA. Its maximum leakage current is 1 μA. Its test current is 31.2 mA. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This zener diode has an operating temperature range of -55 °C to 150 °C. It is made in a single configuration. This zener device has a nominal voltage of 12 V and a voltage tolerance of 5%.
Chip1Stop:
Diode Zener Single 12V 5% 3W 2-Pin SMA T/R
Verical:
Diode Zener Single 12V 5% 3W 2-Pin SMA T/R
Newark:
# MICRO COMMERCIAL COMPONENTS 3SMAJ5927B-TP Zener Single Diode, 12 V, 3 W, DO-214AC, 5 %, 2 Pins, 150 °C
容差 ±5 %
针脚数 2
正向电压 1.5V @200mA
耗散功率 3 W
测试电流 31.2 mA
稳压值 12 V
正向电压Max 1.5 V
额定功率Max 3 W
工作温度Max 150 ℃
工作温度Min -55 ℃
安装方式 Surface Mount
引脚数 2
封装 DO-214AC-2
长度 4.6 mm
宽度 2.9 mm
高度 2.44 mm
封装 DO-214AC-2
工作温度 -55℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
