Conn; Term Blk; Universal; Screw; 4; 26-10AWG; Blue; 6.2mm
端子块 位置
得捷:
CONN TERM BLK FEED THRU 10-26AWG
欧时:
Feed-through terminal block
艾睿:
Never worry about wires becoming undone by implementing this universal terminal blocks 3044584 PCB terminal block developed by Phoenix Contact. This F connector has 4 F contacts. This is a 4-row connector. It has a maximum voltage rating of 500 V. It has a female type gender. 3044584 is housed in polyamide. This device has a maximum current rating of 39 A. This product is 65.4 mm long, 55 mm tall and 6.2 mm deep. Its wire is 10-26 AWG. It uses the screw termination method.
Allied Electronics:
Conn; Term Blk; Universal; Screw; 4; 26-10 AWG; Blue; 6.2 mm
Verical:
Conn Feed-Through Terminal Block F 4 POS Screw T DIN Rail 32A
MASTER:
Feed-through terminal block - nom. voltage: 500 V - nominal current: 32 A - connection method: Screw connection - number of connections: 4 - cross section: 0.14 mm² - 6 mm² - AWG: 26 - 10 - width: 6.2 mm - height: 46.9 mm - color: blue - mounting type: N
Online Components:
Conn Feed-Through Terminal Block F 4 POS Screw T DIN Rail 39A
Electro Sonic:
Feed-through terminal block - nom. voltage: 500 V - nominal current: 32 A - connection method: Screw connection - number ...
