3008025

TB 系列### TB Series

TB 系列

得捷:
CONN TERM BLK FEED THR 1/0-18AWG

欧时:
Feed-through terminal block

艾睿:
Need to ensure strong connections between circuits? This feed-through terminal block 3008025 PCB terminal block from Phoenix Contact will do just that! This F connector has 2 F contacts. It has a female type gender. This is a 2-row connector. It has a straight body orientation. It has a maximum voltage rating of 1000 V. 3008025 is housed in polyamide. This device has a maximum current rating of 150 A. Its wire is 1/0-18 AWG. This product is 50 mm long, 69.5 mm tall and 15.2 mm deep. It uses the screw termination method.

Allied Electronics:
Terminal Block; 18-1⁄ 0 AWG; Screw; 0.75 to 35 mm²; 15.2 mm; Blue

Verical:
Conn Feed-Through Terminal Block F 2 POS Screw ST G DIN Rail/T DIN Rail 125A

MASTER:
Feed-through terminal block - nom. voltage: 1000 V - nominal current: 125 A - connection method: Screw connection - number of connections: 2 - cross section: 0.75 mm² - 50 mm² - AWG: 18 - 1/0 - width: 15.1 mm - color: blue - mounting type: NS 35/7,5 - NS

Online Components:
Conn Feed-Through Terminal Block F 2 POS Screw ST G DIN Rail/T DIN Rail 150A

Electro Sonic:
Feed-through terminal block - nom. voltage: 1000 V - nominal current: 125 A - connection method: Screw connection - number ...
