Conn Fuse Modular Terminal Block F 2POS Screw RA Cable Mount 32A
Fuse modular terminal block, Connection method: Screw connection, Cross section: 1.5 mm2\- 25 mm2, AWG: 16 - 4, Nominal current: 32 A, Nominal voltage: 690 V, Width: 54 mm, Fuse type: Class CC, Fuse type: Glass, Mounting type: NS 35/7,5, NS 35/15, Color: black
得捷:
CONN TERM BLK DISCONNECT 6-18AWG
欧时:
Conn; Term Blk DIN Rail Fuse Lever-type
艾睿:
Say goodbye to wires becoming undone by using this 3048603 PCB terminal block developed by Phoenix Contact. This F connector has 2 F contacts. It has a female type gender. This is a 1-row connector. It has a maximum voltage rating of 690 V. It has a right angle body orientation. This device has a maximum current rating of 32 A. 3048603 is housed in polyamide. It uses the screw termination method. Its wire is 4-16 AWG.
Allied Electronics:
Conn; Term Blk; DIN Rail; Fuse; Lever-type
Verical:
Fuse Modular Terminal Block F 2 POS Screw RA Cable Mount 32A
MASTER:
Fuse modular terminal block - fuse type: Glass / ceramics / ... - connection method: Screw connection - cross section: 1.5 mm²- 25 mm² - AWG: 16 - 4 - nominal current: 32 A - nom. voltage: 690 V - width: 54 mm - fuse type: Class CC - mounting type: NS 35/
Online Components:
Conn Terminal Block F 2 POS Screw RA Cable Mount 32A
Electro Sonic:
Fuse modular terminal block - fuse type: Glass / ceramics / ... - connection method: Screw connection - cross section: ...
