Sensor: thermostat; Output conf: NO; Topen:27℃; Tclos:43℃; 10A
恒温器 110°F(43°C) SPST-NO 圆柱形,带安装法兰 快速连接
得捷:
THERMOSTAT 43DEG C SPST-NO CYL
贸泽:
Thermostats 0 C to + 260 C Temperature Sensors
艾睿:
Redi Temp Ceramic Thermostat Automatic Reset Close on Rise 2-Pin
Allied Electronics:
Commercial Thermal
TME:
Sensor: thermostat; Output conf: NO; Topen:27°C; Tclos:43°C; 10A
Verical:
Redi Temp Ceramic Thermostat Automatic Reset Close on Rise 2-Pin
Newark:
# HONEYWELL 3455RC 01000245 Thermostat, Automatic Reset, 3455RC Series, 43 °C, Normally Closed, Flange Mount
Powell:
Sensors, Thermal , Thermostats
DeviceMart:
THERMOSTAT CERAMIC 43.3DEG C NO
额定电流 15A, 10A
触点类型 SPST
额定电流Max 15 A
工作温度Max 260 ℃
工作温度Min 0 ℃
额定电压 120VAC, 240VAC
额定电压AC Max 240 V
接触电阻Max 50 mΩ
引脚数 2
封装 Cylinder with Mounting Flange
封装 Cylinder with Mounting Flange
工作温度 0℃ ~ 260℃
外壳材质 Ceramic
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
