3455RC 01000249概述

Sensor: thermostat; Output conf: NO; Topen:71℃; Tclos:88℃; 10A

恒温器 190°F(88°C) SPST-NO 圆柱形,带安装法兰 快速连接


得捷:
THERMOSTAT 88DEG C SPST-NO CYL


贸泽:
Thermostats Commercial Thermal/ PRECISION COML CERAM


艾睿:
Ceramic Automatic Reset Thermostat


Allied Electronics:
Commercial Thermal


TME:
Sensor: thermostat; Output conf: NO; Topen:71°C; Tclos:88°C; 10A


Powell:
Sensors, Thermal , Thermostats


3455RC 01000249中文资料参数规格
技术参数

额定电流 15A, 10A

额定电流Max 15 A

工作温度Max 260 ℃

工作温度Min 0 ℃

额定电压 120VAC, 240VAC

接触电阻Max 50 mΩ

封装参数

安装方式 Screw

引脚数 2

封装 Cylinder with Mounting Flange

外形尺寸

封装 Cylinder with Mounting Flange

物理参数

工作温度 0℃ ~ 260℃

外壳材质 Ceramic

其他

产品生命周期 Active

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free
