3455RC 01000240概述

Sensor: thermostat; Output conf: NC; Topen:135℃; Tclos:118℃; 10A

恒温器 275°F(135°C) SPST-NC 圆柱形,带安装法兰 快速连接


得捷:
THERMOSTAT 135DEG C SPST-NC CYL


艾睿:
Ceramic Automatic Reset Thermostat


Allied Electronics:
Thermostat, Redi-Temp Series Ceramic Automatic Reset


TME:
Sensor: thermostat; Output conf: NC; Topen:135°C; Tclos:118°C; 10A


Powell:
Sensors, Thermal , Thermostats


3455RC 01000240中文资料参数规格
技术参数

额定电流Max 15 A

工作温度Max 260 ℃

工作温度Min 0 ℃

接触电阻Max 50 mΩ

封装参数

安装方式 Screw

引脚数 2

封装 Cylinder with Mounting Flange

外形尺寸

封装 Cylinder with Mounting Flange

物理参数

工作温度 0℃ ~ 260℃

外壳材质 Ceramic

其他

产品生命周期 Active

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买3455RC 01000240
型号: 3455RC 01000240
描述:Sensor: thermostat; Output conf: NC; Topen:135℃; Tclos:118℃; 10A
