3505 MC005

ALPHA WIRE  3505 MC005  带状电缆, 彩色编码扁平, 多重, 5 芯, 22 AWG, 0.35 mm², 100 ft, 30.5 m

The is a 5-core unshielded Ribbon Cable with stranded tinned copper conductor and a colour-coded PVC insulator bonded into a flat configuration. It facilitates easier routing and termination, taking up less space than wire harness bundles. It is designed to safely carry more current than round harnesses of similar wire gauges and is easy to separate and route within circuit.

.

27lbs Maximum pull tension

.

0.2µH/ft Nominal inductance

.

16.2R/1000ft at 20°C Nominal conductor DC resistance DCR
