3214J-1-203E

BOURNS  3214J-1-203E  微调电位器, 20K, 4MM

0.25W，1/4W J 引线 表面贴装型 微调电位计 金属陶瓷 匝 侧面调节

得捷:
TRIMMER 20KOHM 0.25W J LEAD SIDE

欧时:
Bourns 5 转 表面贴装 微调电阻器 3214J-1-203E, 带J 形钩接端, 20kΩ ±10%, 0.25W, ±100ppm/°C

贸泽:
Trimmer Resistors - SMD 4mm SQ 20K OHM

艾睿:
This 3214J-1-203E potentiometer from Bourns is designed to optimize functionality and calibrate the resistance in your circuit. This product has a resistance value of 20K Ohm. This part has a power rating of 0.25 1/4 W. Its temperature coefficient is ±100 ppm/°C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. The 3214J-1-203E part has a j-hook termination style. It has a tolerance of 10%. This product is 4.8 mm long, 3.71 mm tall and 5 mm deep. This device utilizes cermet technology. This part has an operating temperature of -65 to 150 °C.

Allied Electronics:
Trimmer; Cermet; 5-Turn; 20K Ohm; 0.25 W; 600 VAC; 10%; Side Adjust

安富利:
Res Cermet Trimmer 20K Ohm 10% 1/4W 5ElecTurn 1.5mm 4.8 X 5 X 3.71mm J-Hook SMD Embossed T/R

Chip1Stop:
Res Cermet Trimmer 20K Ohm 10% 0.25W1/4W 5ElecTurn 1.5mm 4.8 X 5 X 3.71mm J-Hook SMD Embossed T/R

TME:
Potentiometer: mounting; horizontal, multiturn; 20kΩ; 250mW; SMD

Verical:
Res Cermet Trimmer 20K Ohm 10% 0.25W1/4W 5ElecTurns 1.5mm 4.8 X 5 X 3.71mm J-Hook SMD T/R

Newark:
# BOURNS  3214J-1-203E  Trimmer Potentiometer, Multiturn, 20 kohm, 250 mW, ± 10%, 3214J Series, 5 Turns

MASTER:
Trimmer Potentiometer - 20K Ohm - 0.25W1/4W - 5ElecTurns - 4.8 X 5 X 3.71mm - J-Hook - Surface Mount.

Electro Sonic:
Trimmer Potentiometer - 20K Ohm - 0.25W1/4W - 5ElecTurns - 4.8 X 5 X 3.71mm - J-Hook - Surface Mount.
