3296 - 3/8 “方可调电位器?微调电位器 3296 - 3/8 ” Square Trimpot® Trimming Potentiometer
10 kOhms 微调电位计 25.0 匝
得捷:
TRIMMER 10K OHM 0.5W PC PIN TOP
艾睿:
This 3296W-1-103ALF potentiometer from Bourns is your solution to resistance calibration in a circuit. This product has a resistance value of 10K Ohm. This part has a power rating of 0.5 1/2 W. Its temperature coefficient is ±100 ppm/°C. This part has an operating temperature of -55 to 125 °C. This device utilizes cermet technology. This product is 9.53 mm long, 11.55 mm tall and 4.83 mm deep. It has a tolerance of 10%. The 3296W-1-103ALF part has a pin termination style.
安富利:
Res Cermet Trimmer 10K Ohm 10% 1/2W 25ElecTurn 2.19mm 9.53 X 4.83 X 11.55mm Pin Thru-Hole Ammo Pack
Chip1Stop:
Res Cermet Trimmer 10K Ohm 10% 0.5W1/2W 25ElecTurn 2.19mm 9.53 X 4.83 X 11.55mm Pin Thru-Hole Ammo Pack
Electro Sonic:
Res Cermet Trimmer 10K Ohm 10% 0.5W1/2W 25ElecTurns 2.19mm 9.53 X 4.83 X 11.55mm Pin Thru-Hole Ammo
容差 ±10 %
额定功率 0.5 W
电阻 10 KΩ
工作温度Max 125 ℃
工作温度Min -55 ℃
安装方式 Through Hole
封装 Square - 0.375" L x 0.190" W x 0.395" H 9.53mm x 4.83mm x 10.03mm
长度 9.53 mm
宽度 4.83 mm
高度 11.55 mm
封装 Square - 0.375" L x 0.190" W x 0.395" H 9.53mm x 4.83mm x 10.03mm
工作温度 -55℃ ~ 125℃
温度系数 ±100 ppm/℃
产品生命周期 Active
包装方式 Ammo Pack
RoHS标准 RoHS Compliant
含铅标准 Lead Free
